In this guide, we will explore common Vestel washing machine error codes, explain their meanings, and provide effective solutions to fix them. Understanding these error codes is the first step towards troubleshooting and resolving any problems.
Let’s learn how to fix error codes on your Vestel washing machine, empowering you to tackle any issues that may arise with your washer.
Understanding the Vestel Washing Machine Error Codes and Messages
Remember to always unplug the washer and exercise caution when attempting any repairs.
E01: Door Lock Error
A door lock error on a Vestel washing machine occurs when there is an issue with the door locking mechanism. This error is triggered when the machine fails to detect that the door is properly closed.
Solutions:
- One common reason for the E01 error is attempting to start the washing cycle before fully closing and locking the door.
- Always ensure the door is securely closed before pressing the Start/Pause button.
- Make sure that the door is not partially open or obstructed by any items that could prevent it from closing properly.
- The door lock is connected to the washing machine’s control board via a wire harness.
- Ensure that the wire connections are secure and not damaged. Loose or faulty connections can lead to the E01 error.
- Over time, the door hinge can become misaligned or loose, preventing the door from closing properly.
- Inspect the hinge and tighten any loose screws to ensure the door operates smoothly.
- The door lock assembly has a resistance value that can be measured from terminal 3 to terminal 4. A reading of around 292 Ω indicates the lock is functioning correctly.
- If the resistance is significantly different, it may indicate a faulty door lock that needs replacement.
- In some cases, a malfunctioning main control board could be causing the door lock error.
- If all other components are in working order, replacing the main board may be necessary to resolve the problem.
E02: Water Inlet Error.
A water inlet error on a Vestel washing machine occurs when the machine faces difficulties filling up with water during the start of a wash cycle. This error is typically triggered due to issues with the water supply or problems with the water inlet valve.
Solutions:
- Low water supply pressure can hinder the proper filling of the washing machine.
- Ensure that the water supply to the machine is sufficient and the water pressure is within the recommended range specified in the user manual.
- The water inlet valve is equipped with a filter to prevent debris and sediments from entering the machine. Over time, this filter can become clogged, impeding water flow.
- Clean the filter regularly to ensure smooth water intake.
- A clogged detergent drawer can also obstruct water flow into the machine.
- Make sure the detergent drawer is clean and free from any detergent residue or blockages.
- Inspect the wire connections to ensure they are secure and not damaged.
- Loose or faulty connections can lead to the E02 error.
- The water inlet valve has a resistance value that can be measured. Use a multimeter to check the resistance, and it should read around 3.7 KΩ.
- A significant deviation from this value may indicate a faulty inlet valve that needs replacement.
- In some cases, a malfunctioning main control board could be causing the water inlet error.
- If all other components are in working order, replacing the main board may be necessary to resolve the problem.
E03: Drain Pump Error
A drain pump error on a Vestel washing machine occurs when the machine is unable to drain water effectively during the wash, rinse, or spin cycle. This error is typically caused by issues with the drain pump or its components.
Solutions:
- The drain pump is equipped with a filter to catch lint, debris, and foreign objects from the water. Over time, this filter can become clogged, restricting water flow and causing the E03 error.
- Regularly clean the drain pump filter to ensure proper drainage.
- Ensure that the drain pump hose is not bent, kinked, or blocked. A bent or blocked hose can impede the smooth flow of water, leading to drainage issues.
- Straighten the hose and remove any obstructions if necessary.
- Inspect the wire connections to ensure they are secure and free from damage.
- Loose or damaged connections can cause the E03 error.
- Use a multimeter to measure the resistance of the drain pump motor coil. The resistance value should read around 138 Ω.
- If the resistance significantly deviates from this value, it may indicate a faulty drain pump motor that needs replacement.
- If the steps above don’t resolve the issue, consider replacing the main board. Sometimes, a malfunctioning main control board can be the underlying cause of the drain pump error.
- If all other components are in good condition, replacing the main board may be necessary to fix the problem.
E04: Overflow Error
An overflow error on a Vestel washing machine occurs when the machine detects an excessive amount of water in the drum during a wash cycle. This error is typically caused by issues related to water drainage, water inlet, or pressure regulation.
Solutions:
- The water inlet valve is responsible for allowing water to enter the washing machine. Verify that the valve can shut off the water supply properly when the required water level is reached.
- If the valve doesn’t close properly, water may continue to fill the drum, causing an overflow.
- The pressure hose regulates the water level in the washing machine. Ensure that the hose is not bent or damaged and doesn’t have any pinholes that could affect the pressure sensing mechanism.
- A faulty pressure hose can cause inaccurate water level measurements, leading to overflow errors.
- The air chamber is connected to the pressure hose and helps maintain the correct pressure for water level detection.
- Make sure the air chamber is clean and free from any obstructions, as debris or blockages can interfere with the water level sensing process.
- If the steps above don’t resolve the overflow issue, it’s possible that a malfunctioning main control board could be causing the E04 error.
- If all other components related to water flow are functioning correctly, replacing the main board may be necessary to fix the problem.
E05: Washer Heater or NTC Error
A washer heater or NTC error on a Vestel washing machine occurs when there is a problem with the washer’s heating system or the NTC (negative temperature coefficient) sensor.
Solutions:
- Inspect the wire connections to ensure they are secure and free from damage.
- Loose or faulty connections can cause the E05 error.
- The NTC sensor is also connected to the control board through a wire harness.
- Ensure the wire connections are secure and not damaged.
- Faulty connections can lead to inaccurate temperature readings and trigger the E05 error.
- Ensure the wire connections are secure and not damaged.
- Calcium and mineral deposits can accumulate on the heater assembly over time, hindering its performance and causing temperature irregularities.
- Regularly clean the heater assembly to ensure efficient heating during the wash cycle.
- Calcium deposits can also affect the NTC sensor’s accuracy in detecting water temperature.
- Clean the NTC sensor to remove any buildup and ensure it provides accurate temperature readings.
- Measure the resistance of the heater using a multimeter. The resistance value should read around 27 Ω.
- A significantly different reading may indicate a faulty heater that needs replacement.
- Measure the resistance of the NTC sensor using a multimeter. The resistance value should be between 11 and 13 KΩ.
- If the reading is outside this range, it may indicate a faulty NTC sensor that requires replacement.
- Sometimes, a malfunctioning main control board can be the underlying cause of the E05 error.
- If all other components related to heating and temperature sensing are in good condition, replacing the main board may be necessary to fix the problem.
E6: Motor Error
A motor error on a Vestel washing machine occurs when there is a problem with the motor or its related components. Additionally, the related error code E08: Motor TRIAC error code indicates issues with the TRIAC component responsible for controlling the motor speed.
Solutions:
- Inspect the connections to ensure they are secure and free from damage. Loose or faulty connections can cause the E6 error.
- The DC motor board, which controls the motor’s operation, is also connected through a wire harness.
- Verify that the connections are in good condition and properly seated.
- The motor’s bearing allows it to spin smoothly. Over time, the bearing may wear out or become faulty, causing the motor to malfunction.
- Inspect the bearing and replace it if necessary.
- The tachometer generator is responsible for providing feedback about the motor’s speed to the control system.
- A short circuit in the tachometer generator can lead to inaccurate readings, triggering the E6 error.
- The motor brush is a critical component that conducts electricity to the motor’s rotor.
- Worn-out brushes can cause motor issues and should be replaced if needed.
- Use a multimeter to measure the resistance of the tachometer generator, and it should read around 180 Ω.
- A significantly different reading may indicate a faulty tachometer generator.
- Measure the motor’s resistance using a multimeter. The values should be around 2.1 Ω for rotor winding, 1.20 Ω for low-speed winding, and 3.30 Ω for high-speed winding.
- Deviations from these values may indicate motor problems.
- A malfunctioning DC motor board can be the root cause of the motor error.
- Replacing the board can rectify the problem if other components are in working order.
- Sometimes, the main control board may be causing the motor error.
- If all other components related to the motor are in good condition, replacing the main board may be necessary to fix the problem.
E09: Voltage Error
E09: A voltage error on a Vestel washing machine occurs when the appliance detects a voltage level under 200 Vac during its operation. This error is triggered when the voltage supplied to the washing machine is insufficient.
Solutions:
- The first step in troubleshooting the E09 error is to check the power supply voltage.
- Ensure that the washing machine is receiving a stable voltage of at least 200 Vac. Fluctuations or drops in voltage below this threshold can trigger the error.
- Inspect the power cable of the washing machine to ensure it is not damaged or frayed.
- A faulty power cable can result in an inconsistent power supply and lead to voltage-related errors.
- If all power-related components are functioning correctly but the E09 error persists, it may indicate a malfunctioning main control board.
- Replacing the main board can help rectify the issue if other components are in proper working order.
E10: EPS Error.
An EPS Error (Electronic Pressure Sensor) on a Vestel washing machine occurs when there is a problem with the electronic pressure sensor responsible for detecting water levels inside the washing machine’s drum.
Solutions:
- Inspect the wire connections to ensure they are secure and free from damage.
- Loose or faulty connections can cause the E10 error, as the sensor may not provide accurate readings to the control board.
- The pressure sensor itself may become faulty over time due to wear and tear or other issues.
- If both the wire harness and the pressure sensor are functioning correctly, yet the E10 error persists, it could indicate a problem with the main control board.
- Replacing the main board may be necessary to address the issue if other components are in working order.
E11: Dryer Board Communication Malfunction
Dryer Board Communication Malfunction on a Vestel washing machine occurs when there is a breakdown or communication issue between the main control board and the dryer board. The dryer board is responsible for controlling the drying function of the washing machine. This could happen due to various reasons, such as a loose or damaged wire harness or a malfunctioning dryer board.
Solutions:
- Inspect the wire connections to ensure they are secure and free from damage.
- Loose or faulty connections can cause the E11 error as it disrupt communication between the boards.
- If the wire harness is in good condition but the E11 error persists, the dryer board itself may be faulty.
- Replacing the dryer board can rectify the communication malfunction and restore the drying function.
- If both the wire harness and the dryer board are functioning correctly, yet the E11 error persists, it could indicate a problem with the main control board.
- Replacing the main board may be necessary to address the issue if other components are in working order.
E12: 3D Sensor Error
An E12 error on a Vestel washing machine occurs when there is an issue with the 3D sensor, which is responsible for measuring the position of the wash unit and sending signals to the main control board regarding the actual loading.
The 3D sensor plays a crucial role in ensuring the balance and stability of the wash unit. It helps the washing machine to detect the load distribution inside the drum. If the 3D sensor encounters any problems or malfunctions, it may not provide accurate readings to the main control board, leading to the E12 error.
Solutions:
- Overloading the washing machine with an excessive amount of laundry can disrupt the balance of the drum, leading to issues with the 3D sensor.
- Avoid overloading the washer to prevent the E12 error.
- Placing the washing machine on an uneven or unstable surface can cause the drum to be misaligned. This can impact the performance of the 3D sensor, resulting in errors.
- Ensure the washer is placed on a level and stable surface.
- The 3D sensor relies on a magnet and sensor elements to function properly. A broken or damaged magnet or sensor element can cause inaccuracies in the sensor’s readings, leading to the E12 error.
- Inspect the wire connections to ensure they are secure and free from damage.
- Loose or faulty connections can cause communication issues between the 3D sensor and the main board.
- Visually inspect the 3D sensor for any physical damage or abnormalities. If you notice any issues, the sensor may need to be replaced.
- If all other components related to the 3D sensor are in working order but the E12 error persists, it could indicate a problem with the main control board.
- Replacing the main board may be necessary to address the issue if other components are functioning correctly.
E14: Dryer Heater, Fan, Inlet Valve, High Limit Error
E14: Dryer Heater, Fan, High Limit Error on a Vestel washing machine occurs when there are issues related to the dryer heater, fan, or high limit safety component in the drying system.
Solutions:
- Inspect the wire connections to ensure they are secure and free from damage.
- The dryer fan, responsible for circulating hot air during the drying process, is also connected through a wire harness.
- Verify that the connections are in good condition and properly seated.
- Inspect the dryer fan blade for any obstructions or damage that may hinder its rotation.
- A blocked or damaged fan blade can affect airflow and lead to drying issues.
- Ensure the wire connections to the high-limit safety device are secure and functioning correctly.
- The water inlet valve has a resistance value that can be measured. Use a multimeter to check the resistance, and it should read around 4.3 KΩ.
- Measure the resistance of the dryer heater using a multimeter.
- The resistance value should fall between 60 and 73 Ω.
- A reading outside this range may indicate a faulty heater that needs replacement.
- The resistance value should fall between 60 and 73 Ω.
- Measure the resistance of the dryer fan using a multimeter. The resistance value should read around 86 Ω.
- A significantly different reading may indicate a faulty fan that requires replacement.
- Ensure that the high limit is functioning correctly and resetting as intended.
- Visually inspect the dryer heater, fan, and high limit for any physical damage or abnormalities.
- If you notice any issues, the affected component may need to be replaced.
- Check the dryer board and replace it if necessary.
- If all other components related to the drying system are in working order but the E14 error persists, it could indicate a problem with the main control board.
- Replacing the main board may be necessary to address the issue if other components are functioning correctly.
E18: Dryer NTC Sensor Error.
A dryer NTC sensor error on a Vestel washing machine occurs when there is a problem with the NTC sensor in the washer/dryer section.
Solutions:
- Inspect the wire connections to ensure they are secure and free from damage.
- Loose or faulty connections can cause the E18 error, as it may disrupt communication between the sensor and the main board.
- Measure the resistance of the NTC sensor using a multimeter.
- The resistance value should read between 19 and 21 KΩ at 25 °C. If the reading is significantly different from this range, it may indicate a faulty NTC sensor that needs replacement.
- If the NTC sensor and its wire harness are functioning correctly, yet the E18 error persists, it could indicate a problem with the dryer control board.
Conclusion:
Understanding the error codes displayed by the Vestel washing machine’s control panel is crucial for effective troubleshooting and resolving any issues that may arise during its operation. Each error code indicates specific problems related to different components, such as the door lock, water inlet, drain pump, motor, voltage, and various sensors.
