Our guide provides an overview of error codes for Smeg washing machines. The codes are divided into two categories: those that begin with EXX and those that begin with FXX.
Each code will be explained in detail to help diagnose and troubleshoot any issues that may arise with your washing machine.
SMEG Washing Machine Error Codes that begin with Exx
When troubleshooting error codes on specific Smeg washing machine models, it’s crucial to note their initial manufacturer, Beko. Consequently, when investigating error codes, it is advisable to reference the fault codes employed by Beko, which typically start with “Exx.” To simplify this process, we’ve compiled a comprehensive list of these codes and their corresponding explanations in this article.
| Error codes | Meanings |
|---|---|
| E01 | NTC sensor error. |
| E02 | Heating element error. |
| E03 | The heater relay stuck. |
| E04 | The washer keeps filling with water. |
| E05 | Drain pump error. |
| E06 | Universal DC motor TRIAC short circuit error |
| E07 | Pressure level sensor error. |
| E08 | Water inlet valve error. |
| E09 | Door lock TRIAC open circuit error |
| E11 | BLDC motor error. |
| E12 | Water leakage error. |
| E14 | Recirculation pump error |
| E15 | Water liter counter error |
| E17 | overfoaming warning. |
| E18 | Unbalanced load warning |
| E22 | LCD communication failure error |
| E24 | Fill sensor error. |
| E26 | EEPROM error. |
| E29 | Voltage out of limit error. |
| E31 | Dryer NTC sensor error |
| E35 | Dryer heating element error |
| E37 | Drum overheating warning |
| E38 | NTC sensor in-drum overheating. |
| E45 | No variable file version was detected. |
| E84 | Network card failure. |
Please check the link provided to access this list and find diagnostic and solution information.
SMEG Washing Machine Error Codes that begin with Fxx
F16, F34, F36, and F61: Door lock error
The error indicates that the door lock does not activate, and no program activates because the porthole door is open.
Causes:
- The porthole door is open.
- Faulty door microswitch
Solutions:
- Close the door.
- Check the door lock.
- Check the door lock wiring.
- Replace the door lock if necessary.
F17, F26, F27 and F31: Pressure switch error
The error indicates that the solenoid valve of the machine is taking too long to fill with water.
Causes:
- The water tap is closed.
- The intake water pressure is below 1 bar.
- The water intake filter or supply is blocked.
- Faulty solenoid valve.
- Faulty pressure switch.
Solutions:
- Open the water tap.
- Check the inlet valve.
- Check the pressure switch hose / clean the chamber pressure.
- Check the pressure switch.
- Check the wiring connections.
F18: Drain pump error.
The error indicates that the washer takes too long to drain.
Causes:
- The drain pump is blocked.
- Faulty drain pump
- Faulty pressure switch.
- The pressure switch chamber is blocked.
- The drainage tube is blocked.
Solutions:
- Switch the washer off and back on to reset.
- Check the drain pump.
- Check the pressure switch.
- Check the wiring.
F19: Heater element error.
The error indicates that the water heating element takes too long to heat up.
Causes:
- Faulty heater.
- The voltage is low.
- The heating element relay is blocked.
- Faulty main PCB
Solutions:
- Check the heating element.
- Check the wiring diagram.
- Replace the main PCB.
F20, F37 and F38: NTC (Heater Sensor) error
The error indicates that the heating element activates at a time when it should not be heating up.
Causes:
- Faulty NTC (short or open circuit)
- The heating element relay is blocked.
- Faulty main PCB
Solutions:
- Check the NTC
- Replace the main PCB.
F23: Leakage error.
The error indicates that water is present at the bottom of the machine.
Causes:
- Problems in the water safety system.
- The water leakage activates the microswitch.
- The safety float is blocked.
- Faulty safety float
Solutions:
- Check the water stop system.
- Check the safety float microswitch located at the bottom of the machine.
- Check the wiring connections.
F28: Flow meter error.
The error indicates that the water intake unit is not working.
Causes:
- Faulty harness.
- Faulty flow meter sensor
Solutions:
- Check the wiring diagram.
- Replace the flow meter sensor.
F29, F31 and F60: Inlet valve error
The error indicates that the water is not loaded.
Causes:
- The water tap is closed.
- The intake water pressure is below 1 bar.
- The inlet valve filter is blocked.
- Faulty inlet valve.
- Faulty aqua stop.
- Faulty main PCB
Solutions:
- Open the water tap.
- Check the inlet.
- Check the wiring connections.
- Replace the main PCB.
F42, 43 or 44: Motor error
The error indicates that there is no alternating rotation of the motor.
Causes:
- Faulty harness connector.
- Faulty carbon brush.
- Faulty tachometer.
- Faulty motor.
- Faulty TRIAC.
- Circuit board problem.
Solutions:
- Carry out a test cycle to reset.
- Check the load / bearings.
- Check the carbon brush.
- Check the tachometer.
- Check the motor resistance
- Check the wiring connections
- Check the main PCB.
F59: 3D sensor error.
The error indicates that the number of turns during the spin is reduced.
Causes:
- Defective wiring connection.
- Faulty 3D sensor
- The 3D sensor magnet is not correctly positioned.
- Faulty main PCB
Solutions:
- Check the wiring.
- Position the 3D sensor magnet correctly.
- If the error still occurs, replace the 3D sensor.
- Check the main PCB.
F63 or F67: Main PCB error
The error indicates a malfunction of the software circuit board or main PCB.
Causes:
- Faulty circuit board microprocessor.
- Software problems.
Solutions:
- Switch the washer off and back on again, using the ON/OFF button to reset.
- If the error code still appears, replace the circuit board (the main PCB).
