This blog post provides a reference chart for the temperature sensor in Samsung refrigerators. It can be helpful for troubleshooting purposes.
Key:
- °C (temperature in Degrees Celsius)
- °F (temperature in Degrees Fahrenheit)
- Voltage: electrical voltage measured by the sensor.
- Resistance: electrical resistance of the sensor.
Chart:
The chart lists the following sensor types:
- Room temperature sensor
- Refrigerator sensor
- Freezer sensor
- Ice maker sensor
- Refrigerator defrost sensor
- Freezer defrost sensor
For each sensor type, the chart provides corresponding values in °C, °F, and (where applicable) voltage and resistance.
Samsung Refrigerator Temperature Sensor Chart: Temperature table
This table provides a reference guide for common temperature sensors in Samsung refrigerators. Temperatures are listed in both Celsius (°C) and Fahrenheit (°F).
| °C | °F | Voltage Vdc | Resistance KΩ |
|---|---|---|---|
| -10 | 14 | 3.356 | 20.41 |
| -5 | 23 | 3.107 | 16.14 |
| 0 | 32 | 2.853 | 13.29 |
| 5 | 41 | 2.599 | 10.82 |
| 10 | 50 | 2.350 | 8.86 |
| 15 | 59 | 2.111 | 7.30 |
| 20 | 68 | 1.885 | 6.05 |
| 25 | 77 | 1.67 | 5.03 |
| 30 | 86 | 1.483 | 4.21 |
| 35 | 95 | 1.30 | 3.54 |
| 40 | 104 | 1.153 | 2.99 |
Here are some things to keep in mind:
- The table includes voltage and resistance readings, which may be useful for advanced troubleshooting.
- This table applies to all Samsung refrigerator models.
